Cerwin Vega VPAS12 12" Powered Car Subwoofer with Passive Radiator

Cerwin Vega VPAS12 12" Compact Powered Car Subwoofer with Passive Radiator

The Cerwin Vega VPAS12 is a 12-inch compact powered subwoofer designed to deliver deep, powerful bass without taking up valuable interior space. Featuring a built-in amplifier and passive radiator in a slim enclosure, it provides an all-in-one bass solution that easily integrates with both factory and aftermarket car audio systems. Its compact design makes it ideal for installation under seats, in trunks, or in other tight mounting locations.

Compact Powered Bass for Any Vehicle

The Cerwin Vega VPAS12 combines a 12-inch subwoofer, passive radiator, and integrated amplifier into a single compact enclosure, eliminating the need for a separate amplifier or large subwoofer box. Its space-saving design makes it an excellent choice for cars, trucks, and SUVs where interior space is limited but powerful bass is still a priority.

• 12-inch compact powered subwoofer with passive radiator
• Built-in amplifier for an all-in-one bass solution
• Slim enclosure for space-saving installation
• Fits under seats, in trunks, or other tight spaces
• Dimensions: 13.5" W × 11.25" L × 3" H

Deep Bass with Passive Radiator Technology

The 12-inch subwoofer is paired with a passive radiator to create a highly efficient bass system that delivers deeper, more impactful low frequencies from a compact enclosure. The integrated amplifier provides the power needed for strong, controlled bass performance while maintaining a slim profile.

• 250 watts RMS power handling
• 600 watts peak power
• 4-ohm impedance
• Frequency response: 30 Hz – 150 Hz
• High-output slim-profile subwoofer design

Easy Integration and Installation

Designed for plug-and-play installation, the Cerwin Vega VPAS12 is compatible with both factory and aftermarket radios. Flexible input options and adjustable controls make it easy to integrate into a variety of vehicle audio systems while allowing you to fine-tune bass performance.

• Compatible with factory and aftermarket head units
• RCA high-level inputs
• Low-pass filter: 85 Hz – 150 Hz
• Phase inversion switch: 0° or 180°
• Input sensitivity: 0.9V – 12V (high level), 0.3V - 5V (low level)

Durable Design with Convenient Controls

The integrated amplifier is housed in a cast aluminum enclosure that functions as a heatsink for efficient heat dissipation and dependable performance. A wired bass knob allows quick adjustment from the driver's seat, while onboard tuning controls let you tailor the bass to your listening preferences.

• Cast aluminum heatsink enclosure
• Wired bass knob included
• Vega Bass boost: 0 to 12 dB
• Subsonic filter: 30 Hz
• 25A fuse
• Recommended 8-gauge power and ground wiring

---

FAQs

1. Can the Cerwin Vega VPAS12 fit under a vehicle seat? Yes. Its slim 3-inch-high enclosure is designed for installation under seats, in trunks, or in other compact mounting locations.
2. Can it be used with a factory radio? Yes. The VPAS12 is compatible with both factory and aftermarket head units for easy system integration.
3. Does the Cerwin Vega VPAS12 include an amplifier? Yes. It features a built-in amplifier, making it a complete all-in-one powered subwoofer solution.
4. Is a remote bass control included? Yes. A wired bass knob is included, allowing convenient bass level adjustment from the driver's seat.
5. What are the power ratings? The VPAS12 is rated to handle 250 watts RMS and 600 watts peak power.
